A
nickel chromium resistance wire is strung through and supported by a
ceramic core. Finely meshed refractory material is vibrated through
the remaining air voids to provide good thermal conductivity and
dielectric strength. The sheath is seamless stainless steel and with
proper surface contact and application considerations can provide
sheath temperatures to 900°F/485°C. Because of ease of installation,
Channel Heaters have been used in many industrial
applications, such as platens, hot plates, dies, molds, mill slots
or any place surface heat is required. Figures TF2 and TF3 can be
used as air heaters or in oven applications.
Type P Protective Terminal Box Cover: On T3 Terminal only. Prevents damage to terminals from grounding, short circuiting and foreign material. |
Type W without Mounting Tabs |
Type L & Type
R Both items have 1/2" NPT internal threads for conduit attachment and are contamination resistant. Type L is shown with welded-on mounting tabs. Type R can also be manufactured with welded-on tabs. |
Type C Armor Cable for abrasion resistant leads. |
Type O Ceramic Terminal Cover: To protect against electrical shock. Wire exit at any angle. Available on Type T1 and T3. |
Type S Teflon Seal: (450°F Maximum) Resists moisture or contaminant from entering terminals. |
